AquaMax Eco Expert

• Brushless DC pumps are powerful, energy efficient filtration pumps for demanding filter systems and large waterfalls


• OASE AquaMax Eco Expert are next generation pumps outstandingly suited for extremely powerful and economical water delivery


• Patented frost protection protects against freeze damage down to -4°F while grounding plate safeguards against stray current


• Integrated Environmental Function Control automatically shuts off the pump in run dry conditions to prevent motor damage


• Patented Seasonal Flow Control (SFC) slows flow and reduces wattage up to 50% as water temperatures drop


• Submersed or inline installation in a variety of water types, including chlorinated pool and salt water


• Eco Control and Garden Cloud Controller operate and monitor pump remotely

OASE’s AquaMax Eco Expert brushless DC pumps are powerful, energy efficient filtration pumps for demanding filter systems and large waterfalls. OASE AquaMax Eco Expert are next generation pumps outstandingly suited for extremely powerful and economical water delivery. Robust stainless steel intake screen passes debris particles up to 0.44". Unique patented frost protection safeguards pump from freeze damage down to -4°F while integrated grounding plate safeguards against stray current. Integrated Environmental Function Control automatically shuts off the pump in run dry conditions to prevent motor damage. Patented Seasonal Flow Control (SFC) slows water flow, lowers head height and reduces wattage when temperatures drop in response to lower cool season demand, for up to 50% energy savings. Submersed or inline installation in a variety of water types, including chlorinated pool and salt water. Eco Control and Garden Cloud Controller operate and monitor pump remotely; Eco Control via manual control, Garden Cloud Controller via wifi application. Unlike Direct Drive pumps, which are susceptible to suction cavitation and pump damage, the AquaMax Eco Expert has no minimum head height for operation. It qualifies for the OASE Clear Water Guarantee when paired with the proper filter and UVC Clarifier. The AquaMax Eco Expert 6800 has 220-240V / 50-60 Hz, 2 amps and a 2” outlet. It has a 33’ power cord, dimensions of 19”L x 8.5”W x 8”H and a Sch40 1.5”-2” adapter. The AquaMax Eco Expert 6800 has a max flow of 6800 GPH and a 5-year warranty.

• AquaMax Eco Expert Manual
